DSH 600-X Petrol cut-off saw (300mm)
Compact top-handle petrol saw (63cc) with blade brake, for cutting up to 120 mm with 300 mm blades in concrete, masonry and metal
- Motor cylinder: 63.3 cm³
- Rated power: 3.2 kW
- Wet or dry operation: Wet and dry
Technical Data
Motor cylinder
63.3 cm³
Rated power
3.2 kW
Wet or dry operation
Wet and dry
Dimensions (LxWxH)
558 x 326 x 370 mm
Fuel mixture
50:1 (2% oil)
A-weighted emission sound pressure level
102 dB (A) 1
Disc diameter
300 mm
Cutting depth
120 mm
Triaxial vibration value for cutting concrete slab (ah)
2.5 m/s² 2
- According to the applicable product standard (see the Operating Instruction for more details)
- According to the applicable product standard (see Operating Instruction for more details)
Documents
Features & Applications
Features
- Top-handle design for even more compactness and lighter weight
- Fast blade stop – the blade stops in less than 10 seconds
- Cutting depth up to 120 mm with 300 mm blades
- Achieve even higher cutting speeds by using with customised Hilti blades
- Pre-tensioned belt – no belt maintenance required by the user
Applications
- Laying paving – cutting kerbstones and paving slabs to size
- Masonry work – cutting bricks and blocks to size
- Metalwork – cutting steel profiles, pipes and steel sheets
- Construction work – cutting out openings in brick or concrete walls
- Sewage work – cutting where working space is limited
For approval or certificate information, please see individual items.
