Highlights

Reduce anchor channel design time

PROFIS Anchor Channel calculating and modeling software is designed to help you produce more accurate fastening points in concrete using anchor channels in less time. The fastening calculations are supported by the most up-to-date modeling codes and regulations.

All-in-one software to help increase productivity

Complete your calculations and choose a fastening solution from recommendations based on the calculated scenarios. The software can then generate a design report, including formulas, code and approval references and anchor channel specifications.

Improve accuracy

Fastening calculations for almost every scenario, including seismic and dynamic loading, are based on customized, pre-approved parameters in accordance with regional building regulations. You can calculate anchor channel systems for various design regulations and loads using calculations according to ICC-ES AC232, ACI 318-08, 318-10, 318-11, and ACI 349.

Solve for complex scenarios using the Hilti Design Method

The Hilti Design Method helps solve for anchor channel detailing not included in standard design guidelines, enabling you to find more efficient solutions for complex anchor combinations.

Simplify the transition to fastening using cast-in anchor channels

This software makes it easier to make the switch from designing with traditional alternatives. Compared to traditional cast-in technologies, anchor channels help you save on skilled labor as they require no welding. Additionally, anchor channels can reduce the installation time per connection, improve jobsite safety and increase structural reliability.

Specialist support available from Hilti

Your local Hilti anchor channel team is on hand to provide additional information and guidance when designing.

Technical Data

Consulting & Support

HOW TO DESIGN ANCHOR CHANNELS

Hilti PROFIS Anchor Channel

Add over 60 years of Hilti expertise on anchor channels to your own, to design façades, lift shafts and other anchor channel applications.

Hilti PROFIS Anchor Channel design software is based on a wide range of design methods. It includes international codes ACI, EOTA, CEN, SA:TS101 or design using our own Hilti design methods based on more than 60 years of anchor fastening expertise and research.

Hilti PROFIS Anchor Channel design software helps to save you time:

  • Find solutions faster using the software's geometry adjustment feature
  • Optimisation functions help you to find the right solution for your application
  • You can also input custom plates using the custom geometry function

Hilti PROFIS Anchor Channel is used all over the world and has designed core elements of major structures and skyscrapers in Hong Kong, China, the Middle East and the United States.

If you need help, we can also offer local Hilti engineering advice.

Or if you’re working on a particularly daring or innovative build – then our global engineers can support you. They can think through with you just how far you can safely take our Hilti anchor channels and solutions.

ACCESS HILTI PROFIS ANCHOR CHANNEL

You can access Hilti PROFIS Anchor Channel free of charge here at Hilti website. Just sign up or log in.

OUR HILTI ENGINEERING SERVICE

If you’d like help with your design, our expert Hilti engineers can design anchor channel fastener systems for you. For more information, contact your local Hilti team.
